Instruction

ACEPOM312T endoscope vibration meter is mainly used for the detection of machinery vibration parameters including : displacement, velocity (intensity) and acceleration. Based on the parameter collected from the bearing set , ISO2372 and default specification of machine & company,   we can judge the condition (Good, warning or dangerous) of machines ( Fan, pump, compressor, motor, etc).

Since the mid-1980s, this instrument has been used by large and medium-sized enterprises in China, and has been sold more than 20,000 sets so far. With very low repair rate, it is an ideal point inspection instrument.

Parameter：

Acceleration probe：Piezoelectric shear acceleration probe

Measurement range：　acceleration：0.1～199.9m/s2

　　　　　　           velocity：　0.1～199.9 mm/s

　　　　　　           displacement：　0.001～1.999 mm

accuracy：　±5％±2digit

Frequency range：　 acceleration：10Hz～1kHz(LO)，1kHz～15kHz(HI)

Velocity ：　　　10Hz～1kHz

displacement：　　　10Hz～1kHz

Display：　　　3-1/2digital display，refresh1s，push “MEAS”to measure，release to hold value

Output：　AC output，2V in full range

　　　　　　Access to headset VP-37

　　　　　　The load impedance 10kΩ or more　

Battery：　　　1 * 9V battery to support work over 25h

Automatic power off if no operation within 1 minute　

Environment：-10～50℃，<90％RH

Size：　　　185(H)×68(H)×30(D) mm

Weight：　　　250 g

Standard configuration：

1·host   1

2·Battery   1

3·Short test pole S   　1

4·Belt    1

5·Manual   1

6.Long test pole   1

7.Sound insulation headset   1
