Portable dynamic balancer ACEPOM30

The intelligent way to field balancing

simple – fast – accurate

The BalancerACEPOM30 is a portable measuring device for field balancing. Its complete operating philosophy is based on our current CAB measuring units, and offers the same precision and convenience, meaning that it can be quickly integrated into your business without complicated familiarisation or training.

The mobile field balancing machine from the experts

The statistics are indisputable: Over 50% of all faults and failures of machines and systems can be attributed directly or indirectly to unbalances in rotors. The SmartBalancer helps you to identify an unbalance simply and accurately, and to correct it with the minimum effort. This ensures the reliability of your machines and systems, and increases your competitiveness.    With the SmartBalancer, rotors of almost any size and weight can be balanced quickly, costeffectively and accurately in the installed condition, and therefore without having to dismantle the machine.Thanks to the comprehensive diagnosis capabilities, the SmartBalancer keeps you uptodate with the vibration condition of your machines and therefore keeps your business running.

Operation

Make your work easier with the high operating convenience

With the BalancerACEPOM30 you have everything under control at all times and in one hand. All functions of the unit can be operated easily and intuitively by means of navigation keys and a few function keys, even by inexperienced users. The brilliant colour display with its easily understandable pictograms and the simple file structure are based on the commonly used Windows presentation. This makes the SmartBalancer an efficient and practical tool for tracking down unbalances during ongoing operations.

Benefit from our complete package for field balancing

Even the basic scope of delivery contains everything you need for field balancing: Everything required for immediate use is provided, from the acceleration sensor, laser reference pickup with magnetic stand and all required connection cables, to the power supply unit/charger and USB connection cable. Further functionalities are available as options. This makes the SmartBalancer an indispensable instrument in your business – an untiring worker and analyst.

Features

A tool with many talents

The BalancerACEPOM30 is outstanding for its comprehensive measurement and analysis functions, which offer you valuable services for field balancing. It is also ideally suitable for the commissioning, service and maintenance of machines and systems. From the measurement, assessment and diagnosis of the machine condition, to the assessment of the roller bearings or the bump test, to documentation and archiving of all the results: The BalancerACEPOM30 is a genuine smart instrument – for many applications over and above field balancing.

An platinum field balancer ACEPOM30 instead of the old model 1200, mainly in the instrument processor has been further updated, processing data faster, the sensor all imported highprecision sensors, instead of the old domestic sensors, measurement results more accurate.

The ACEPOM30 field balancer can quickly determine the operating status of the equipment at the site and analyze whether the equipment has any malfunction. If it exists, you can use the test weight method or influence coefficient method provided by the system to perform dynamic balance correction. The system will automatically calculate the mass and angle of the plus (minus) weight. In many cases, one balancing correction can remove more than 90% of the unbalance of the rotor (shaft).

Onsite dynamic balancing technology is an extremely wide range of practical technologies used by industrial and mining enterprises. The use of onsite dynamic balancing technology can use a very short time to solve the problem of poor dynamic balance of the rotor or shaft of the equipment without changing the original installation conditions of the equipment, thereby greatly reducing the cost of disassembly, transportation, installation and maintenance. The business brings obvious economic benefits.

An platinum field balancer ACEPOM30 main functions:

Wizardtype balancing function: The software quickly solves the counterweight quality and its angle according to the measurement data, and provides a fully-guided dynamic balancing function. The operator can easily complete the dynamic balance correction by simply pressing the wizard.

Vector decomposition: Perform a reasonable vector decomposition on the balanced quality of the solution to meet the objective requirements of field installation.

Balance method: Test weight method and influence coefficient method.

Trial Estimation: Based on the input rotor data, a reasonable dynamic balance test weight is automatically estimated, and the conclusion of dynamic balance effect can be given.

Fault diagnosis function: Before balancing, you can perform some fault diagnosis first to ensure that the cause of the fault is bad dynamic balance and avoid blind dynamic balance; this function can diagnose common faults of the equipment and it can be used in one machine.

Balanced report: After the balancing process is completed, the software can automatically generate a dynamic balance report to clarify the basic information of the rotor, vibration reduction and detailed weight information. Technical indicators:

Vibration measurement accuracy: ±3%

Speed measurement range: 50~30000r/min

Speed measurement accuracy: ± 1‰± 1 character

Display: full Chinese interface

Storage: 128KB

Volume: 190 × 100 × 50 (mm) (collector)

Weight: 800g (collector)

An platinum field balancer ACEPOM30 configuration list:
